7X19 stainless steel wire rope 1.2mm 304

Symbols of Stainless Steel Wire Ropes The SS Wire Rope currently used on the crane is mainly a common type of structural Stainless Steel Wire Rope, rope 6×19 and rope 6×37. According to the rules of the national standard "Round-strand Stainless Steel Wire Rope" (GB1102-74), the symbol method of stainless steel wire rope is as follows: For example, stainless steel wire rope 6×37-15.0-170-I one armour one plating one right cross GB1102-74 This means that the round strand stainless steel wire rope is made of 6 strands, the structure method of the strands is point contact, each share has 37 steel wires, the fiber rope core, the diameter of the stainless steel wire rope is 15.0mm, and it is made of No. 1 with a nominal tensile strength of 1700MPa. Group A is made of pot-plated steel wire, and the twist direction of the stainless steel wire rope is right alternating twist. Fourth, the selection of stainless steel wire rope The lower the nominal tensile strength of the stainless steel wire rope at the same diameter, the more steel wires in each rope, and the thinner the wire diameter, the better the flexibility of the rope, but the stainless steel wire rope is easy to wear. On the contrary, the thicker the diameter of the steel wire in each rope, the worse the flexibility of the stainless steel wire rope, and the wear resistance of the stainless steel wire rope. Therefore, different types of stainless steel wire ropes have different application ranges. According to the actual needs of lifting and hoisting operations, in general, the selection of stainless steel wire rope can consider the following principles: (1) 7X19 Stainless Steel Wire Rope is used as cable wind rope, cable and lifting rigging, and is generally used for receiving Where bending loads are small or where they are subject to wear. (2) 6×37 stainless steel wire ropes are used for bundling various objects, equipment, threading and wrapping pulleys and making rigging for lifting. Suitable for when the rope is bent. (3) 6×61 stainless steel wire rope is used to bind various objects. The rope has less rigidity and is easy to bend, and is used in places where there is not much impact. The stainless steel wire rope with the same direction twist has a flat and soft surface, has excellent anti-bending fatigue function, and is more durable; its defect is that the rope strands are easy to slack when the rope head is broken, and it is easy to rotate when suspending heavy objects, and it is easy to bend and kink. , so it should not be used alone in hoisting. Lifting and hoisting operations are commonly used to store alternately twisted stainless steel wire ropes. 5. The force calculation of stainless steel wire rope There is a certain limit to the maximum tensile force allowed by a certain standard stainless steel wire rope. If this limit is exceeded, the stainless steel wire rope will be damaged or broken. Calculate the force of the wire rope.
It workes perfectly for the deckwithout blocking your view.

High tension strength 7x19-8mm 316 wire rope

Ideal cable for standing rigging on boats, steel cable railings, deck railings.

Construction: 7X19

Grade: 316

Breaking Strength: 1760 lbs
Surface: polished, shine
Features: cut without separating, high quality.
Package: Normally wooden spool.
