Brand: HTWR
Surface Treatment: Zinc, Plain
Place Of Origin: China
Structure: Welded Chain
Features: Conveyor Chain, Transmission Chain, Drag Chain, Tyre Protection Chain
Is It A Standard Part: Standard, Nonstandard
Packaging: 1.Gunny Bag 2. Iron Drum 3.Plastic Drum 4. Wooden Box 5. Plastic Reel 6. Per your requirement
Productivity: 50 ton/month
Transportation: Ocean,Land,Air
Place of Origin: Jiangsu
Supply Ability: 50 ton/month
Certificate: ISO9001
HS Code: 73158200
Port: Shanghai
Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF,EXW
Galvanized Link Chain
We offer a wide range of premium marine grade SS Wire Rope and Galvanized Link Chain in many different diameters. From long chains to spiked and heavy duty chains, our products are ideal for a variety of applications including marine, ship mooring and lifting for domestic and commercial purposes.
We also supply galvanized chains for Short Link Chain and Stainless Steel Long Link Chain, as well as various chain hooks, connectors.
Specifications
| Item Name | Specifications |
| DIN 766 Link Chain |
|
| Size | Inside Length (A) | Inside Width (C) | Outside Width (B) | Length per 11 Links | Weight per M | ||||
| MM | MM | +MM | -MM | MM | MM | MM | +MM | -MM | KG |
| 2 | 12 | 0.2 | 0.2 | 3.5 | 7.5 | 132 | 1.0 | 0.5 | 0.07 |
| 3 | 16 | 0.2 | 0.2 | 4.2 | 11 | 176 | 1.4 | 0.7 | 0.16 |
| 4 | 16 | 0.3 | 0.2 | 5 | 13.7 | 176 | 2.1 | 1.1 | 0.32 |
| 5 | 18.5 | 0.4 | 0.2 | 6 | 17 | 203.5 | 2.4 | 1.2 | 0.5 |
| 6 | 18.5 | 0.4 | 0.2 | 7.2 | 20.2 | 203.5 | 2.4 | 1.2 | 0.8 |
| 7 | 22 | 0.4 | 0.2 | 8.4 | 23.8 | 242 | 3 | 1.4 | 1.1 |
| 8 | 24 | 0.4 | 0.2 | 9.6 | 27.2 | 264 | 3.2 | 1.5 | 1.4 |
| 9 | 27 | 0.5 | 0.3 | 10.8 | 30.6 | 297 | 3.6 | 1.8 | 1.8 |
| 10 | 28 | 0.5 | 0.3 | 12 | 34 | 308 | 3.7 | 1.9 | 2.2 |
| 11 | 31 | 0.5 | 0.3 | 13.2 | 37.4 | 341 | 4 | 2 | 2.7 |
| 12 | 36 | 0.6 | 0.3 | 14.4 | 40.8 | 396 | 4.4 | 2.2 | 3.10 |
| 13 | 36 | 0.6 | 0.3 | 15.6 | 44.2 | 396 | 4.6 | 2.4 | 3.8 |
| 14 | 41 | 0.7 | 0.4 | 16.8 | 47.6 | 451 | 5.4 | 2.7 | 4.4 |
| 16 | 45 | 0.8 | 0.4 | 19.2 | 54.4 | 495 | 6 | 3 | 5.7 |
| 18 | 50 | 0.8 | 0.4 | 21.6 | 61.2 | 550 | 6.6 | 3.3 | 7.3 |
| 19 | 53 | 0.9 | 0.4 | 22.8 | 64.6 | 583 | 7.0 | 3.7 | 7.97 |
| 20 | 56 | 1 | 0.5 | 24 | 68 | 616 | 7.4 | 3.7 | 9 |
| 23 | 64 | 1.1 | 0.5 | 27.6 | 78.2 | 704 | 8.4 | 4.2 | 12 |
| 26 | 73 | 1.2 | 0.6 | 31.2 | 88.4 | 803 | 9.6 | 4.8 | 15 |
| 28 | 78 | 1.3 | 0.65 | 33.8 | 95.2 | 858 | 10.2 | 5.1 | 18 |
| 30 | 84 | 1.4 | 0.7 | 41.0 | 102 | 924 | 11.0 | 5.5 | 19.5 |
| 32 | 90 | 1.5 | 0.75 | 43.0 | 108.8 | 990 | 11.8 | 5.9 | 23.0 |
Product Categories : Stainless Steel Link Chain > Short Link Chain
